Microprismatic Tape
Product code: MICRO
- Focused retroreflective values
- Micro-engineered 3 point prisms on the surface
- Retroreflective performance of 5 years
- Available in various colors
- Widths from 0.75″ to 47″
- Overview
- Colors
Microprismatic tape is a reflective tape with very high retroreflective values. Suitable for application to objects where visibility needs to be increased.
Benefits
The reason for the high-performance levels is the retro-reflective surface created by man-made 3 point prisms, which return 80% of the light directly back to the source, making this a much higher performing material. So much so that it has a 5-year retro-reflective performance.
It is an engineering grade prismatic tape, commonly referred to as EGP reflective tape. The name is applied due to microprismatics use as a high-performance reflective tape in warehouses and factories.
Unlike our DOT ( Department of Transport ) materials, micro prismatic tape does not carry a certification stamp, enabling it to be used for signage, vehicle wraps and barriers.
Microprismatic tape is suitable for applying to static objects such as posts, barriers and life jackets, as well as mobile objects such as boats, heavy machinery and motorcycles.
Sizes
Microprismatic tape is available in rolls in widths from 3/4″ to 48″ in lengths of 150ft. Die cuts are also available.
For more information or to order, contact the sales team by phone, live chat or the contact us form on the website.
MICRO_R
Pantone / RAL
1795 U / 3020
Average LRV
1.25
MICRO_O
Pantone / RAL
172 U / 3016
Average LRV
14.75
MICRO_Y
Pantone / RAL
109 U / 1026
Average LRV
70.75
MICRO_F
Pantone / RAL
3965 U / 7027
Average LRV
100
MICRO_V
Pantone / RAL
Green U / 6032
Average LRV
7.25
MICRO_B
Pantone / RAL
3005 U / 5005
Average LRV
2
MICRO_W
Pantone / RAL
7541 U / 7035
Average LRV
46.50
Light Reflectance Values
| Product code | Color | Av. LRV | Range |
|---|---|---|---|
| MICRO_R | Red | 1.25 | 1 |
| MICRO_O | Orange | 14.75 | 2 |
| MICRO_Y | Yellow | 70.75 | 7 |
| MICRO_F | Fluorescent Yellow | 100 | 0 |
| MICRO_V | Green | 7.25 | 2 |
| MICRO_B | Blue | 2 | 2 |
| MICRO_W | White | 46.50 | 13 |
Standards
| International (US/Canada) | White, Yellow, Blue, Green, Red | ASTM D4956 Type I |
| Europe | White, Yellow, Blue, Green, Red | EN 12899/1 RA1 |
| Argentina | White, Yellow, Blue, Green, Red | IRAM 10033 |
| Japan | White, Yellow, Blue, Green, Red | JIS Z9117 |
| Australia | White, Yellow, Blue, Green, Red | AS/NZS 1906.1 Class 100 |
| New Zealand | White, Yellow, Blue, Green, Red | AS/NZS 1906.1 Class 100 |
| Korea | White, Yellow, Blue, Green, Red | KS T:3507, Type I |
| Brazil | White, Yellow, Blue, Green, Red | ABNT 14644 Tipo I |
| Russia | White, Yellow, Blue, Green, Red | GOST 55290 Class 1 |
| China | White, Yellow, Blue, Green, Red | GB/T 18833 Type I |
| South Africa | White, Yellow, Blue, Green, Red | SANS 1519-1 |
| International (US/Canada) | Fluorescent Yellow | ASTM D4956 Type III/IV |
| France | Fluorescent Yellow | NF XP9B-502 T2 |
| Argentina | Fluorescent Yellow | IRAM 3952 Class II |
| Japan | Fluorescent Yellow | JIS Z9117 |
| Australia | Fluorescent Yellow | AS/NZS 1906.1 Class 300 |
| New Zealand | Fluorescent Yellow | AS/NZS 1906.1 Class 300 |
| Korea | Fluorescent Yellow | KS T:3507, Type IV |
| Brazil | Fluorescent Yellow | ABNT NBR 14644 Tipo III |
| Mexico | Fluorescent Yellow | N-CMT-5-03-001 Tipo A |
| China | Fluorescent Yellow | GB/T 18833 Type IV |
| Russia | Fluorescent Yellow | GOST 52290National Class 2 |
| Europe | Fluorescent Yellow | EN 12899/1 RA2/R2 |
| South Africa | Fluorescent Yellow | SANS 1519-1 Class 2 |
| International (US/Canada) | Orange | ASTM D4956 Type I |
| Europe | Orange | EN 12899/1 RA1 |
| Argentina | Orange | IRAM 10033 |
| Japan | Orange | JIS Z9117 |
| Australia | Orange | AS/NZS 1906.1 Class 100 |
| New Zealand | Orange | AS/NZS 1906.1 Class 100 |
| Korea | Orange | KS T:3507, Type I |
| Brazil | Orange | ABNT 14644 Tipo I |
| Russia | Orange | GOST 55290 Class 1 |
| China | Orange | GB/T 18833 Type I |
| South Africa | Orange | SANS 1519-1 |
